parkboard PE / PH
Pallet

Product Information

The pallet systems offer optimum area utilisation and can also be retrofitted in existing garages. By means of an electric motor, the park pallets moving on rails are moved longitudinally by a push of a button and then release the required parking space. On unused surfaces and in driving lanes additional parking spaces can be created. ParkBoard PE and ParkBoard PH parking pallets are available for each vehicle.

ParkBoard PE and ParkBoard PH pallets are best suited to residential and commercial buildings, single and multi-family houses, office buildings, underground garages, car parks, hotels, car shops, long and short-term parking and retrofitting into existing buildings.

Project Documents

DATA SHEET – PE / PH (220KB)

TENDER SPECIFICATION – PARKBOARD PE / PH (67KB)

DWG – PARKBOARD PE PH (149KB)

Specifications

  • independent parking
  • one level
  • one vehicle per pallet
  • pallet shifted lengthwise
  • pallet moving on rails
  • indoor system
  • height 100mm lower then ceiling height
  • usable platform width 1,900mm / 2,100mm
  • usable platform length 5,000mm
  • weight options 2.0t/2.3t
  • platform cover StandardGrid
  • push button operation
  • subsequent installation possible depending on local conditions

Accessories

Upgrades and optional extras available for your KLAUS parking system.
